Silver high speed air curtain Silver high speed air curtain Silver high speed air curtain

Silver high speed air curtain

DACN0010

Model No. DACN0010 DACN0011 DACN0015
Dimension (mm) 916 x 360 x 370 1220x 360 x 370 1526x360x370
Max. Air Velocity At Nozzle 24 m/s 24 m/s 24 m/s
Noise Level DB < 65 db < 66 db < 68dB
Body Material Metal Metal Metal
Width Size 3 Feet 4 Feet 5 Feet
No. Of Blowers 2 3 4
No. Of Motors 1 2 2
HP 1.5 2.24 3
Voltage 440V/50Hz 440V/50Hz 440V/50Hz
Power (W) 1100W 1650W 2000W
Phase Three Three Three
RPM (Max/Min) 2700 2700 2700
Blower Material Metallic  Metallic  Metallic
CFM 2200 2950 3680
Effective Height 20-22 Feet 20-22 Feet 20-22 Feet
Weight Kgs. 44 51 64

Dolphy Silver High Speed Air Curtain – DACN0010/DACN0011/DACN0015 is a premium air control solution designed for large commercial and industrial spaces. Built with a sturdy metallic body and high-speed motors, this ceiling-mounted air curtain ensures effective airflow to block dust, insects, and outside air—helping maintain hygiene and energy efficiency indoors.

Ideal for doorways up to 20–22 feet high, this model delivers a powerful air velocity of 24 m/s and operates quietly under 68 dB. Available in 3, 4, and 5-foot widths, it suits a range of entrances and facility types like malls, warehouses, hotels, and hospitals.

Key Features:
• Max Air Velocity: 24 m/s
• Power: 1100W–2000W | Voltage: 440V / 50Hz
• Motor: High-speed metallic blowers (2700 RPM)
• Effective Height: 20–22 Feet
• Noise Level: <68 dB | Body Material: Metal
• Phase: Three-phase | Durable & Reliable

Whether you’re searching for a high-performance air curtain, reliable air cutter machine, or trusted air curtain supplier in India, this model combines power, durability, and energy savings
